FE Specification Chart
| Vehicle | Description | Part # | Dimensions | Weight Capacity (evenly distributed) |
|---|---|---|---|---|
| Full Size 8' Long Bed | Full Extension (FE) | 10-9648-FE | 96"L x 48"W | 1,000 lbs. |
| FE with Xtreme side Rails | 10-9648-FE-XT | 96"L x 48"W | 1,000 lbs. | |
| Full Extension (FE) | 20-9648-FE | 96"L x 48"W | 2,000 lbs. | |
| FE with Xtreme side Rails | 20-9648-FE-XT | 96"L x 48"W | 2,000 lbs. | |
| Full Size 6.5' Short Bed | Full Extension (FE) | 10-7548-FE | 75"L x 48"W | 1,000 lbs. |
| FE with Xtreme side Rails | 10-7548-FE-XT | 75"L x 48"W | 1,000 lbs. | |
| Full Extension (FE) | 20-7548-FE | 75"L x 48"W | 2,000 lbs. | |
| FE with Xtreme side Rails | 20-7548-FE-XT | 75"L x 48"W | 2,000 lbs. | |
| Full Size Super Duty 6'9" Short Bed | Full Extension (FE) | 10-8048-FE | 80"L x 48"W | 1,000 lbs. |
| FE with Xtreme side Rails | 10-8048-FE-XT | 80"L x 48"W | 1,000 lbs. | |
| Full Extension (FE) | 20-8048-FE | 80"L x 48"W | 2,000 lbs. | |
| FE with Xtreme side Rails | 20-8048-FE-XT | 80"L x 48"W | 2,000 lbs. | |
| Full Size 5.5' & 5.8' Short Bed | Full Extension (FE) | 10-6548-FE | 65"L x 48"W | 1,000 lbs. |
| FE with Xtreme side Rails | 10-6548-FE-XT | 65"L x 48"W | 1,000 lbs. | |
| Full Extension (FE) | 20-6548-FE | 65"L x 48"W | 2,000 lbs. | |
| FE with Xtreme side Rails | 20-6548-FE-XT | 65"L x 48"W | 2,000 lbs. | |
| 2015-c F150 5.5 & Tundra Crew Max | Full Extension (FE) | 10-6348-FE | 63"L x 48"W | 1,000 lbs. |
| FE with Xtreme side Rails | 10-6348-FE-XT | 63"L x 48"W | 1,000 lbs. | |
| Full Extension (FE) | 20-6348-FE | 63"L x 48"W | 2,000 lbs. | |
| FE with Xtreme side Rails | 20-6348-FE-XT | 63"L x 48"W | 2,000 lbs. | |
| Midsize 6' Short Bed | Full Extension (FE) | 10-7141-FE | 71"L x 41"W | 1,000 lbs. |
| FE with Xtreme side Rails | 10-7141-FE-XT | 71"L x 41"W | 1,000 lbs. | |
| Full Extension (FE) | 20-7141-FE | 71"L x 41"W | 2,000 lbs. | |
| FE with Xtreme side Rails | 20-7141-FE-XT | 71"L x 41"W | 2,000 lbs. | |
| Midsize 5' Short Bed | Full Extension (FE) | 10-5941-FE | 59"L x 41"W | 1,000 lbs. |
| FE with Xtreme side Rails | 10-5941-FE-XT | 59"L x 41"W | 1,000 lbs. | |
| Full Extension (FE) | 20-5941-FE | 59"L x 41"W | 2,000 lbs. | |
| FE with Xtreme side Rails | 20-5941-FE-XT | 59"L x 41"W | 2,000 lbs. | |
| Midsize 5' Short Bed Frontier | Full Extension (FE) | 10-5641-FE | 59"L x 41"W | 1,000 lbs. |
| FE with Xtreme side Rails | 10-5641-FE-XT | 59"L x 41"W | 1,000 lbs. | |
| Full Extension (FE) | 20-5641-FE | 59"L x 41"W | 2,000 lbs. | |
| FE with Xtreme side Rails | 20-5641-FE-XT | 59"L x 41"W | 2,000 lbs. |
